CNC-LATHES

PUMA-VTR-1216-우측문열림완성--300x300

Vertical lathe:

Doosan Puma VTR 1216M model 2017

Control: Fanuc 0iT-F

Max rotation diameter: Ø1700 mm

Max turning height: 1250 mm

Chuck:  Ø50”  (1250 mm)

Rotating tools

puma-vtr-1620m-정면문열림-밝음-300x300

Vertical lathe:

Doosan Puma VTR 1620M model 2019

Control: Fanuc 0iT-F

Max rotation diameter:  Ø2100 mm

Max turning height:  1800 mm

Chuck:  Ø63”  (Ø1600 mm)

Rotating tools

P_700LM_side_close

Horizontal lathe:

Doosan Puma 700M model 2020

Control: Fanuc 2iT-F

Max rotation diameter: Ø1030 mm

Max turning length: 1600 mm

Chuck: Ø24″ (610 mm)

Rotating tools

PUMA--5100

Horizontal lathe:

Doosan Puma 5100M model 2020

Control:Fanuc 0iT-F

Max rotation diameter: Ø900 mm

Max turning length: 952 mm

Chuck: Ø21″ (530 mm)

Rotating tools

SKT700LM_iso1-300x200

Horizontal lathe:

Hyundai-Kia SKT-700LM model 2010

Control: Fanuc 21iTB

Max rotation diameter: Ø1050 mm

Max turning length: 3250 mm

Chuck: Ø24″ (610 mm)

Rotating tools

L400 Series.pdf

Horizontal lathe:

Hyundai-Wia L400LMC model 2015

Control: Fanuc 32iT

Max rotation diameter: Ø725 mm

Max turning length: 2100 mm

Chuck: Ø15” (380 mm)

Rotating tools

L800MA-300x250

Horizontal lathe:

Hyundai-Wia L800MA model 2018

Control: Fanuc 31i

Max rotation diameter: Ø1050 mm

Max turning length: 1650 mm

Chuck:  Ø32″ (813 mm)

Rotating tools

SKT-300_iso1-298x200

Horizontal lathe:

Hyundai-Kia SKT-300 model 2008

Control: Fanuc 21iTB

Max rotation diameter: Ø750 mm

Max turning length: 720 mm

Chuck: Ø12″ (305 mm)

P_3100ULY_side_open-300x200

Horizontal lathe:

Doosan Puma 3100 ULY model 2018

Control: Fanuc 0iTF

Max rotation diameter: Ø670 mm

Max turning length: 3125 mm

Chuck: Ø 12 ” (315 mm)

Rotating tools

PUMA-GT260-300x180

Horizontal lathe:

Doosan Puma GT 2600 M  model 2018

Control: Fanuc 0iT

Max rotation diameter: Ø630 mm

Max turning length: 610 mm

Chuck: Ø10” (254 mm)

Rotating tools

Hyundai-Wia-SE2200

Horizontal lathe:

Hyundai Wia SE2200 LMSA model 2022

Control: Fanuc 0i Plus

Max turning diameter: Ø300 mm

Max turning length: 520 mm

Counterspindle

Rotating tools

Bar feeder maximum bar size: Ø51 mm

Toshulin-Basicturn

Vertical lathe:

Toshulin Basicturn 1250 C-M

Model 2012

Control: Fanuc 31i-TA

Max rotation diameter: Ø1500 mm

Max turning height: 1200 mm

Chuck: Ø50”  (1250 mm)

Rotating tools

VL_850HR_iso1-300x200

Vertical lathe: 2 pcs

Yu Shine VL 850 HL and  HR model 2008

Control: Fanuc 0iTC

Max rotation diameter: Ø1100 mm

Max turning height: 700 mm

Chuck: Ø24″ (610 mm)

MACHINING CENTERS

HB_2150_iso1-300x200

Double column machining center:

Hartford HB-2150AG
Model 2008

Control: Heidenhain TNC510i

Max travel (X) 2000 mm

Max travel (Y) 1500 mm

Max travel (Z) 780 mm

Spindle: BT-50

NC-rotary table

Manual anglehead

KAPPA_1100_iso1-300x200

Vertical machining center: 2pc

Hartford VMC-1100AG
Model 2008

Control: Fanuc 21iMB

Max travel (X) 1100 mm

Max travel (Y) 610 mm

Max travel (Z) 610 mm

Spindle: BT-50

HWF500Plus-300x200

Vertical machining center:

Hyundai-Wia F500
Model 2018

Control: Fanuc 0i

Max travel (X) 1060 mm

Max travel (Y) 510 mm

Max travel (Z) 635 mm

Spindle: BT-40

DNM6700

Vertical machining center:

DOOSAN PUMA DNM 6700
Model 2019

Control: FANUC 0i MF

Max travel (X) 1300 mm

Max travel (Y) 670 mm

Max travel (Z) 625 mm

Tool magazine: 30 pc

VCF850LSR-II_180314

5-axis machining center:

DOOSAN PUMA VCF 850 LSR
Model 2018

Control: FANUC 31i-5

Max travel (X) 3000 mm

Max travel (Y) 850 mm

Max travel (Z) 800 mm

Vertical head swivel(B) +/- 110°

2 pc Rotary Tables (A&C)

Tool magazine 60 kpl

GENOS-M460V-5AX

5-axis machining center:

OKUMA GENOS M460V
Model 2020

Control: OSP-P300MA-H SUITE

Max travel (X) 762 mm

Max travel (Y) 460 mm

Max travel (Z) 460 mm

Table tilt (A) +20/- 110

Table rotation (C) 360°

Tool magazine: 32 pc

DSC_0137-web

5-axis machining center:

DECKEL MAHO DMU 50
Model 2018

Control: Heidenhein TNC 530

Max travel (X) 500 mm

Max travel (Y) 380 mm

Max travel (Z) 380 mm

Table tilt (2 pc) (B) +90/- 90°

Table rotation (2 pc) (C) 360°

Tool magazine 48 kpl

BORING MACHINES

BMC-110-300x190

Boring machine:

Johnford BMC-110

Control: Fanuc 31i MB

Max travel (X) 2500 mm

Max travel (Y) 1800 mm

Max travel (Z) 1600 mm

2 pallet

Tool magazine 60pcs

BED TYPE MILL MACHINES

3-3-17_0359-bm-4-300x180

5-axis bed type mill machine:

Lagun BM 4

Control: Heidenhain iTNC640

Max travel (X)  4000 mm
Max travel (Y)  1300 mm
Max travel (Z)  1500 mm

Max load  12 tn

Tool magazine 40 pcs
